QMC40-3A Egg Layer Concrete Block Machine
QMC40-3A Egg Layer Concrete Block Machine - Image 2
QMC40-3A Egg Layer Concrete Block Machine - Image 3
QMC40-3A Egg Layer Concrete Block Machine - Image 4

QMC40-3A Egg Layer Concrete Block Machine

Category Tags , , , ,

QT40-3A is egg laying concrete block machine. It can produce different shapes and sizes concrete blocks by changing the moulds. Although this is a small sized block machine, its production capacity can be on a par with middle sized block machine.

ASK FOR A QUOTE

Product Video

Video Content

QMC40-3A is a small sized concrete block machine. The vide show the operation of QMC40-3A.

Product Details：

  1. Raw material: QMC40-3A takes cement, sand, flyash, rubble, slag, stone powder, volcanic ash, water as raw material. You can choose the combination on base of the available raw material at your local area.
  2. Function: QMC40-3A is designed to produce concrete hollow block and concrete solid block. One set block machine can produce different shpaes block by channging the molds. And we also accept block size customization.
  3. Production capacity: Although QMC40-3A is a small sized block machine, its production capacity can be on a par with middle sized block machine because of its perfect structural design. A skilled worker can produce about 3600 pieces 400*150*200mm block in eight hours.
  4. Personnel requirement: The block production process as following, mixing raw material, feeding raw material, pressing bricks. 3 worker will be enough for the produce of the blocks. In order to reduced need for staff and enhance the production capacity, a pan mixer will be needed.
  5. Automation level: QMC40-3A is a semi automatic block machine.
  6. Moulding technology: QMC40-3A adopt vibration moulding technology. The front vibrator and rear vibration rator guarantee the good strength of the blocks.
  7. Power source: QMC40-3A is powered by electric motor.
  8. Other features: QMC40-3A is movable concrete block machine. It only needs some concrete floor to laying the blocks. You don’t need to prepare pallets. That will save investment cost.
  9. Who can purchase this model? This small sized machine is suitable for entrepreneur. They can open a small sized block factory starting to sell concrete blocks.

Technical Parameters：

Dimension of host machine1800*1400*1100mm
Power of host machine6.7 Kw
Weight of host machine1100 Kgs
Mixer modelJQ350
Molding cycle30-50S

The Common Concrete Blocks
